Classified according to DIN EN ISO 6789-22017 Type II Class A, calibrated to a maximum permissible deviation of /- 3 % and thus more accurate than the /- 4 % required by the standard.
Light but robust (because the housing is made of a single piece of aluminium), very workshop-friendly
Tool holder enables an extensive range of accessories
Depending on the tool, work can be carried out either forwards (e.g. open-end spanner) or sideways (e.g. switchable ratchet and socket spanner)
Operation only in the middle of the handle - do not use an extension pipe, as otherwise value shifts may occur
Activation only with insertion tool - otherwise value shifts may occur
Note the gauge block on the certificate
Use only original GEDORE accessories
Extremely low wear due to force reduction on the lever mechanism
Forged lever chain from the in-house GEDORE quality forge
High precision even in heavy continuous use
Long service life and long service life
Simple operation - quick and reliable tightening of the set torque
Convenient setting using an attractively designed, captive adjustment knob at the end of the handle
With test certificate according to DIN EN ISO 6789-22017, traceable to the national standard via the in-house DAkkS laboratory
MountingSeries assembly Production Maintenance and repair
Torque range (min./max.) [nm].
8 Nm - 40 Nm
Type of torque spanner
A-SE
Target groups
AutomotiveIndustry Construction and commercial vehicles Military Energy Mechanical engineering Workshop Utilities Service Railway Agriculture Oil and gas
