What is the adjustable torque range of this torque wrench?

The adjustable range is 2.5 to 12 Nm (22.5 to 106 lbf·in), designed for precise and controlled fastening.

What drive size does the Gedore 753-11 feature?

It features a fixed 1/4" square drive with a ball catch to hold standard 1/4" sockets securely.

How do you know when the set torque is reached?

The wrench mechanism releases automatically with a tactile impulse and an audible click signal.

Does the torque wrench come with a calibration certificate?

Yes, a test certificate according to DIN EN ISO 6789:2017 Type II traceable to DA kkS standards is included.

Is this tool approved for VDE or ESD applications?

No, this torque wrench is not VDE-insulated and not ESD-safe.

GEDORE 753-11 torque spanner DREMOMETER MINI 1/4" 2.5-12 Nm - 1957694

Name: GEDORE 753-11 torque spanner DREMOMETER MINI 1/4" 2.5-12 Nm - 1957694
Brand: GEDORE
SKU: 41986255
Price: 274.8 EUR
Availability: PreOrder
Rating: 7 (1 reviews)

Supplier number: GEDORE 1957694 | EAN 4002805929063

1 review(s)

Recommended Retail Price €529.13

274.80 tax incl.

€227.11 excl. VAT (incl. all environmental contributions)

On order: delivered from 08/10/2026

Ordered before 20:00 - delivered as of 08/10/2026
Free shipping
Delivery by DHL

✆ Talk to a specialist

Controlled fastening with the Gedore wrench

Practical benefits

Clear tactile and audible feedback: You feel a distinct impulse and hear a click as soon as the target torque is reached.
Precise micrometer scale setting: The magnifying window lets you effortlessly configure intermediate values in fine increments of 0.05 Nm.
Lightweight ergonomic housing design: Built with glass-fibre reinforced polyamide and a soft grip, it keeps you comfortable during extended assembly work.

In a nutshell

The right choise for

With the Gedore 753-11 dremometer mini torque wrench, you achieve controlled fastening accuracy on sensitive assemblies. Perfect for working on carbon bicycle components, fine mechanical housings, or M4 to M6 bolts, it reliably protects fragile materials and prevents stripped threads. The adjustable range from 2.5 to 12 Nm can be configured down to fine 0.05 Nm increments using the integrated magnifying window. When the target torque is reached, the wrench provides clear feedback through a tactile impulse and an audible click. Its lightweight glass-fibre reinforced housing with a soft grip ensures comfortable handling throughout the day. This 1/4" wrench comes complete with a din en iso 6789:2017 Type II test certificate.

Product information FAQ Reviews

€274.80

tax incl.

Key features according to our expert

Max. tightening torque: 12 Nm
Drive profile size: 1/4"
VDE approved: No
With safety colour code 1000V: Not applicable
ESD: No
Display: Analogue
Min. tightening torque: 2,5 Nm

Scope of delivery

Torque spanner type MINI,With test certificate according to DIN EN ISO 6789:2017 Type II, traceable to the national standard via the in-house DAkkS laboratory.

Product description

Application Controlled screw tightening in the range 2.5 - 12 Nm / 22.5 - 106 lbf-in
For use in almost all industrial (production) environments
Design Classified according to DIN EN ISO 6789-22017 Type II Class A, incl traceable test certificate, calibrated with a maximum permissible deviation of +/- 3% and thus more accurate than the /- 4% prescribed by the standard.
Torque spanner with 1/4" drive square with ball lock DIN 3120 - A 6.3 as ISO 1174 for controlled clockwise tightening
Automatic switch-off with audible and tactile signal
Light plastic housing made of high-quality, fibreglass-reinforced polyamide with soft component on the handle
Double scale with 0.5 Nm and 5 lbf-in graduations
Additional micrometer scales for setting scale intermediate values, with Nm graduation of 0.05 Nm
Viewing window with magnifying glass effect
Safe locking of the set torque by pressing the setting button
Scope of delivery Torque spanner type MINI
With test certificate in accordance with DIN EN ISO 67892017 Type II, traceable to the national standard via the in-house DAkkS laboratory

All Features

Max. tightening torque: 12 Nm
Drive profile size: 1/4"
Vde approved: No
With safety colour code 1000v: Not applicable
Esd: No
Display: Analogue
Min. tightening torque: 2,5 Nm
Head width 1 [mm].: 28.5 mm
Fixed setting: No
Drive type/drive: Single-sided square
Tightening range (min/max) [lbf-in].: 22.5 lbf-in - 106 lbf-in
Tightening torque (min.) [lbf-ft]: 22.5 lbf-ft
Tightening torque (max.) [lbf-in].: 106 lbf-in
Head height 1 [mm]: 28 mm
Test certificate: DIN EN ISO 6789-2:2017
Scale division [nm]: 5 Nm
Vernier nm: 0.05 Nm
Precision +/-: +/- 3 %
Tightening direction: Turn right
Overall length [mm]: 211 mm
Torque (min.) [nm].: 2.5 Nm
Scale [lbf-in]: 5 lbf-in
Tightening torque (min.) [lbf-in].: 22.5 lbf-in
Tightening range (min/max) [lbf-ft].: 22.5 lbf-ft - 106 lbf-ft
Scope: MountingSeries assembly Production Maintenance and repair
Material: fibreglass-reinforced high-tech polyamide
Torque range (min./max.) [nm].: 2.5 Nm - 12 Nm
Drive square [inch]: 1/4"
Drive square [metric]: 6.3 mm
Target groups: AutomotiveElectronics Industry Precision mechanics Military Energy Mechanical engineering Workshop Service Agriculture Construction switchboard
Turn-off mechanism: Short road clearance
Distance housing - square centre: 14.5 mm
Tightening torque (max) [lbf-ft]: 106 lbf-ft
Calibration length: 130 mm
Torque (max.) [nm].: 12 Nm

Brand GEDORE
41986255
EAN 4002805929063
Supplier number GEDORE 1957694

Frequently asked questions about this product

Answered by specialists

What is the adjustable torque range of this torque wrench?: The adjustable range is 2.5 to 12 Nm (22.5 to 106 lbf·in), designed for precise and controlled fastening.
What drive size does the Gedore 753-11 feature?: It features a fixed 1/4" square drive with a ball catch to hold standard 1/4" sockets securely.
How do you know when the set torque is reached?: The wrench mechanism releases automatically with a tactile impulse and an audible click signal.
Does the torque wrench come with a calibration certificate?: Yes, a test certificate according to DIN EN ISO 6789:2017 Type II traceable to DA kkS standards is included.
Is this tool approved for VDE or ESD applications?: No, this torque wrench is not VDE-insulated and not ESD-safe.
