GEDORE 1.15/0 trigger 3-arm 90x100 mm - 8006000

GEDORE
Supplier number: GEDORE 8006000 | EAN 4036976104639
Recommended Retail Price €101.93
59.80 tax incl.
€49.42 excl. VAT (incl. all environmental contributions)
On order: delivered from 08/10/2026

  • Ordered before 20:00 - delivered as of 08/10/2026
  • Shipping costs €11.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL
✆ Talk to a specialist

Effortless removal with Gedore

Practical benefits
  • Evenly balanced pulling power: The 3-arm design distributes force uniformly to safely pull bearings, gears, and pulleys without tilting.
  • Automatic self-gripping arm design: You prevent slipping under load because the legs automatically press tighter against the workpiece as pressure increases.
  • Compact reach for shafts: A 90 mm spread and 100 mm reach allow you to access components seated on narrow or extended shafts.

In a nutshell

The right choise for

With the Gedore 1.15/0 universal puller, you remove press-fitted bearings, pulleys, and gears with precision and without damaging shafts. The 3 sturdy arms distribute the maximum pulling force of 2.0 tonnes (20 kN) evenly, preventing tilting or slipping during tough extractions. Thanks to the automatic self-gripping leg design, you maintain a secure hold that will not slip as you tighten the M12x1.5 mechanical spindle. Offering a 90 mm spread and 100 mm reach, this puller gives you full control when servicing machinery and automotive components.



Product information FAQ
€59.80
tax incl.

Product information

Key features according to our expert

  • Max. width: 90 mm
  • Hydraulical: No
  • Number of hooks: 3
  • Max. height: 100 mm

Product description

  • Proven, particularly powerful design for pulling discs, wheels, ball bearings, etc.
  • Technical and economic advantages due to variable clamping depth and independent pulling of hooks
  • Particularly suitable for pulling V-belt pulleys and flywheel pulleys mounted on relatively long shafts
  • Suitable for use with a hydraulic spindle

All Features

Max. width
90 mm
Hydraulical
No
Number of hooks
3
Max. height
100 mm
Reversible arms available
No
Clamping bracket available
No
Quick-release lever available
No
Hook foot thickness at end e1 [mm]
2.0 mm
Hook foot depth usable d2 [mm]
9 mm
Suitable for use with a hydraulic spindle
Yes
Screws included
No
Hook foot width on the gripping surface c1 [mm]
14 mm
Number of arms
3
Hooks parallel adjustable
No
Drive hexagonal width
14 mm
Double-sided hooks
No
Towing force (max.) [t]
2
Spindle thread size
M 12x1.5 x 110
Hook brake available
No
Span when pulled externally (max) [mm].
90 mm
Spindle-slide protection
No
Automatic pressing
Yes
Clamping depth usable b [mm]
100 mm
  • Brand GEDORE
  • EAN 4036976104639
  • Supplier number GEDORE 8006000

Frequently asked questions about this product

Answered by specialists
What is the clamping capacity of this universal puller?
The puller has a maximum clamping width of 90 mm and a clamping depth of 100 mm.
What is the maximum pulling force of this model?
This puller can withstand a maximum load of 2.0 tonnes (20 kN).
Is this Gedore puller hydraulically operated?
No, this is a mechanical puller fitted with a mechanical spindle (M12x1.5).
What components can you remove with this 3-arm puller?
It is designed for removing ball bearings, pulleys, gears, and flywheels.
What are the spindle drive specifications?
The spindle has an M12x1.5 thread and is operated using a 14 mm wrench size.
