GEDORE 1.14/2 trigger 2-arm 200x210 mm - 8005380

Name: GEDORE 1.14/2 trigger 2-arm 200x210 mm - 8005380
Brand: GEDORE
SKU: 01041106
Price: 98.95 EUR
Availability: PreOrder

Supplier number: GEDORE 8005380 | EAN 4036976104561

Recommended Retail Price €157.18

98.95 tax incl.

€81.78 excl. VAT (incl. all environmental contributions)

On order: delivered from 08/10/2026

Ordered before 20:00 - delivered as of 08/10/2026
Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
Delivery by DHL

✆ Talk to a specialist

Effortless extraction with the Gedore puller

Practical benefits

Generous reach for deep components: With a 200 mm clamping width and 210 mm depth, you effortlessly access deeply seated pulleys and bearings.
Secure grip without slipping: The two sturdy arms grip components securely so you can apply controlled pulling force without slipping off.
Forged strength for heavy duty: Built with forged crossbars and hooks, the tool lets you remove tightly fitted parts without bending or wear.

In a nutshell

The right choise for

With the Gedore 1.14/2 two-arm universal puller, you remove tight press-fit components safely without damaging underlying shafts or housings. Featuring a clamping width of up to 200 mm and a reach of 210 mm, it easily reaches deep-seated ball bearings, pulleys, gears, and flywheels. The two forged arms provide a firm, secure grip without slipping. Driven by an M 18x1.5 mechanical spindle operated with a standard 19 mm wrench, it delivers controlled high-load pulling force for demanding maintenance and overhaul tasks.

Product information FAQ

€98.95

tax incl.

Key features according to our expert

Max. width: 200 mm
Hydraulical: No
Number of hooks: 2
Max. height: 210 mm

Product description

Proven, particularly powerful design for pulling discs, wheels, ball bearings, etc.
Technical and economic advantages due to variable clamping depth and independent pulling of hooks
Particularly suitable for pulling V-belt pulleys and flywheel pulleys mounted on relatively long shafts
Suitable for use with a hydraulic spindle

All Features

Max. width: 200 mm
Hydraulical: No
Number of hooks: 2
Max. height: 210 mm
Double-sided hooks: No
Clamping bracket available: No
Hook foot thickness at end e1 [mm]: 3.0 mm
Overall length [mm]: 270 mm
Hook foot depth usable d2 [mm]: 16 mm
Suitable for use with a hydraulic spindle: Yes
Screws included: No
Hook foot width on the gripping surface c1 [mm]: 25 mm
Number of arms: 2
Reversible arms available: No
Drive hexagonal width: 19 mm
Towing force (max.) [t]: 5
Spindle thread size: M 18x1.5 x 200
Hook brake available: No
Span when pulled externally (max) [mm].: 200 mm
Spindle-slide protection: No
Automatic pressing: Yes
Clamping depth usable b [mm]: 210 mm

Brand GEDORE
01041106
EAN 4036976104561
Supplier number GEDORE 8005380

Frequently asked questions about this product

Answered by specialists

What are the maximum pulling dimensions of this tool?: This puller has a maximum clamping width of 200 mm and a maximum clamping reach of 210 mm.
Is this puller hydraulically operated?: No, this is a mechanical puller with an M 18x1.5 x 200 mm spindle.
What is the Gedore 1.14/2 universal puller used for?: You use it to remove parts such as belt pulleys, flywheels, wheels, and ball bearings.
How many legs does this model have?: This model has 2 legs designed for steady gripping and extraction.
What wrench size is required to operate the spindle?: You operate the spindle using a 19 mm wrench or socket.
