Can this puller be used for both internal and external pulling?

Yes, by reversing the forged legs, you can easily use the tool as either an internal or external puller.

What are the maximum reach and spread dimensions of this tool?

It provides a clamping reach of 150 mm, with a maximum spread of 170 mm for external pulling and 220 mm for internal pulling.

How does the leg adjustment with the leg brake function?

The leg brake stops unintentional movement. Pressing the button lets you quickly slide the leg along the crossbeam.

Does this puller come standard with a hydraulic spindle?

No, this model uses a mechanical spindle. A hydraulic spindle can be retrofitted optionally if higher force is required.

What is the benefit of the integrated adjustment scale?

The graduated scale helps you align both legs evenly, ensuring centred pulling and optimal force distribution.

GEDORE 1.06/21-B universal puller 2-armed, all-steel hook with hook brake 170x150 mm - 1956353

Name: GEDORE 1.06/21-B universal puller 2-armed, all-steel hook with hook brake 170x150 mm - 1956353
Brand: GEDORE
SKU: 41895868
Price: 140.2 EUR
Availability: PreOrder

Supplier number: GEDORE 1956353 | EAN 4036976120899

Recommended Retail Price €227.48

140.20 tax incl.

€115.87 excl. VAT (incl. all environmental contributions)

On order: delivered from 07/10/2026

Ordered before 20:00 - delivered as of 07/10/2026
Free shipping
Delivery by DHL

✆ Talk to a specialist

Controlled removal with the Gedore puller

Practical benefits

Secure positioning with brake: The integrated leg brake prevents accidental sliding across the crossbeam while you align the tool.
Precise and balanced alignment: A scale helps you set both legs evenly to achieve centric and force-optimised pulling on mechanical components.
Internal and external pulling: You can reverse the rigid forged hooks to switch easily between internal and external pulling tasks.

In a nutshell

The right choise for

With the Gedore 1.06/21-B universal puller, you remove seized bearings, pulleys, and gears with control and without damaging shafts or workpieces. The integrated leg brake prevents unintentional sliding along the crossbeam during positioning, while a push-button release allows quick adjustments. Thanks to the practical alignment scale, you set both legs evenly for a centred and balanced distribution of pulling force. You can easily reverse the rigid forged hooks to switch between internal and external pulling tasks with a clamping reach of 150 mm.

Product information FAQ

€140.20

tax incl.

Key features according to our expert

Max. width: 220 mm
Puller type: Universel puller
Hydraulical: No
Number of hooks: 2
Max. height: 150 mm

Product description

Robust, die-forged design
One-piece forged hooks
With hook brake - protection against unwanted movement of the hooks
Hook can be moved on the crossbeam at the push of a button
If required, the spindle can be replaced by a hydraulic spindle (see table)
Adjustment scale for even setting of the hooks
Enables centric, force-optimised retraction even with very high retraction forces
Exchangeable hooks for different spindle depths are available as accessories

All Features

Max. width: 220 mm
Puller type: Universel puller
Hydraulical: No
Number of hooks: 2
Max. height: 150 mm
Spindle surface coating: Nitrocharacterised
Reversible arms available: Yes
Hooks parallel adjustable: No
Number of arms: 2
Hook foot width on the gripping surface c1 [mm]: 30 mm
Screws included: No
Suitable for use with a hydraulic spindle: Yes
Hydraulic spindle optional: 1.06/HSP1
Hook foot depth usable d2 [mm]: 24 mm
Scale present: x
Hook foot thickness at end e1 [mm]: 3.5 mm
Quick-release lever available: No
Clamping bracket available: No
Anti-slip protection on the spindle available: No
Spindle thread size: G 1/2 x 210
Towing force (max.) [t]: 5,0
Drive hexagonal width: 22 mm
Spindle print piece type: Spitze
Hook brake available: Yes
Span for internal pull a2 (min.) [mm]: 80 mm
Span for internal pulling a2 (max.) [mm]: 220 mm
Span when pulled externally (max) [mm].: 170 mm
Spindle-slide protection: No
Spindle-point interchangeable: No
Implementation: 2-armed
Clamping depth usable b [mm]: 150 mm

Brand GEDORE
41895868
EAN 4036976120899
Supplier number GEDORE 1956353

Frequently asked questions about this product

Answered by specialists

Can this puller be used for both internal and external pulling?: Yes, by reversing the forged legs, you can easily use the tool as either an internal or external puller.
What are the maximum reach and spread dimensions of this tool?: It provides a clamping reach of 150 mm, with a maximum spread of 170 mm for external pulling and 220 mm for internal pulling.
How does the leg adjustment with the leg brake function?: The leg brake stops unintentional movement. Pressing the button lets you quickly slide the leg along the crossbeam.
Does this puller come standard with a hydraulic spindle?: No, this model uses a mechanical spindle. A hydraulic spindle can be retrofitted optionally if higher force is required.
What is the benefit of the integrated adjustment scale?: The graduated scale helps you align both legs evenly, ensuring centred pulling and optimal force distribution.
