GEDORE 1.06/2 universal puller 2-arm 160x150 mm - 8000580

GEDORE
Supplier number: GEDORE 8000580 | EAN 4036976104189
Recommended Retail Price €211.00
124.60 tax incl.
€102.98 excl. VAT (incl. all environmental contributions)
On order: delivered from 09/10/2026

  • Ordered before 20:00 - delivered as of 09/10/2026
  • Shipping costs €6.99 VAT included | Free shipping for orders over a total amount of 125 euros
  • Delivery by DHL
✆ Talk to a specialist

Controlled pulling with Gedore

Practical benefits
  • Perfectly centered pulling force: The integrated adjustment scale lets you align both legs symmetrically to ensure centered and smooth load distribution.
  • Internal and external use: You can quickly reverse the arms to switch between inside and outside gripping for various components.
  • Sturdy drop forged build: The heavy-duty forged construction gives you dependable strength when removing tightly seated bearings and gears.

In a nutshell

The right choise for

With the Gedore 1.06/2 universal puller, you remove stuck bearings, gears, pulleys, and wheels without damaging the shaft or workpiece. The integrated adjustment scale allows you to position the two legs symmetrically and centered, ensuring a smooth and evenly distributed pulling force. You can easily reverse the legs to switch between external and internal pulling applications. Its drop forged construction delivers dependable rigidity and stability across a clamping spread of up to 160 mm and a reach of up to 150 mm. Driven by a mechanical spindle, it gives you full control during maintenance and overhaul tasks in the workshop.



Product information FAQ
€124.60
tax incl.

Product information

Key features according to our expert

  • Max. width: 160 mm
  • Number of hooks: 2
  • Max. height: 150 mm
  • Hydraulical: No
  • Puller type: Universel puller

Product description

  • Tried-and-tested model for safely and quickly loosening discs, wheels, ball bearings, etc.
  • Robust, die-forged design
  • If required, the spindle can be replaced by a hydraulic spindle (see table)
  • Adjustment scale for even setting of the hooks
  • Enables centric, force-optimised retraction even with very high retraction forces
  • Exchangeable hooks for different spindle depths are available as accessories
  • Suitable for use with a hydraulic spindle (see table)

All Features

Max. width
160 mm
Number of hooks
2
Max. height
150 mm
Hydraulical
No
Puller type
Universel puller
Clamping bracket available
No
Quick-release lever available
No
Hook foot thickness at end e1 [mm]
3.5 mm
Overall length [mm]
245 mm
Reversible arms available
Yes
Hook foot depth usable d2 [mm]
18 mm
Suitable for use with a hydraulic spindle
Yes
Hydraulic spindle optional
1.06/HSP1
Screws included
No
Hook foot width on the gripping surface c1 [mm]
30 mm
Number of arms
2
Hooks parallel adjustable
No
Scale present
x
Drive hexagonal width
22 mm
Anti-slip protection on the spindle available
No
Towing force (max.) [t]
5,0
Spindle thread size
G 1/2 x 210
Hook brake available
No
Span for internal pull a2 (min.) [mm]
80 mm
Span for internal pulling a2 (max.) [mm]
220 mm
Span when pulled externally (max) [mm].
160 mm
Spindle-slide protection
No
Spindle-point interchangeable
No
Clamping depth usable b [mm]
150 mm
  • Brand GEDORE
  • EAN 4036976104189
  • Supplier number GEDORE 8000580

Frequently asked questions about this product

Answered by specialists
What are the maximum clamping dimensions of this puller?
The Gedore 1.06/2 has a maximum clamping spread of 160 mm and a maximum clamping reach of 150 mm.
Can this puller be used for both internal and external pulling?
Yes, reversing the puller legs allows you to use the tool for both external and internal extraction.
Is this puller hydraulically operated?
No, this model uses a standard mechanical spindle and is not hydraulic.
How do you adjust the puller legs evenly?
The crossbar features a built-in scale for uniform and centered adjustment of the legs.
What is the Gedore 1.06/2 primarily designed for?
This 2-arm universal puller is designed for safely removing bearings, pulleys, gears, and wheels.
