Product description:
- Functions
- Current, voltage and resistance measurement
- Capacitance and frequency measurement
- Ionisation current measurement (µA DC range)
- Temperature measurement
- Call-through test
- Low-pass filter
- Inrush current measurement
- Non-contact voltage detection
- DC current function
- Display of mixed AC+DC currents (TRMS)
- Display of mixed voltages (TRMS)
Additional info:
- Automatic range selection
- Zero setting, relative value measurement
- Integrated measured value memory (Data Hold, MIN/MAX)
- Jaw opening 35 mm
- Automatic switch-off
- Main product features
- Exact measurement of lower currents (Amp-Tip)
- Displays rotating field direction and motor rotation direction, illuminated display
- Measurement of ionisation current (µA DC range) in heating systems
Key features according to our expert
-
Max. voltage AC/DC: 600 V
-
Measurement temperature: Yes
-
Digital: Yes
-
Battery type: AAA
-
Low battery message: Yes
-
Automatic shut-off: Yes
-
With current clamp: Yes
-
Diode test: Yes
-
Continuity test: Yes
-
Max. current AC/DC: 600 A
-
Measurement Lo-Z: No
-
Measurement of noise: No
-
Measurement of electrical capacity: Yes
-
Measurement frequency: Yes
-
Measurement resistance: No
-
Current measurement: Yes
-
Measurement voltage: Yes
-
Max. electrical capacity: 2500 µF
-
Max. frequency: 1 kHz
Specifications / All features
-
Brand:
BEHA-AMPROBE
-
02910312
-
EAN:
0095969770934
-
Supplier number:
BEHA-AMPROBE 4560615
- Max. voltage ac/dc
- 600 V
- Measurement temperature
- Yes
- Digital
- Yes
- Battery type
- AAA
- Low battery message
- Yes
- Automatic shut-off
- Yes
- With current clamp
- Yes
- Diode test
- Yes
- Continuity test
- Yes
- Max. current ac/dc
- 600 A
- Measurement lo-z
- No
- Measurement of noise
- No
- Measurement of electrical capacity
- Yes
- Measurement frequency
- Yes
- Measurement resistance
- No
- Current measurement
- Yes
- Measurement voltage
- Yes
- Max. electrical capacity
- 2500 µF
- Max. frequency
- 1 kHz
