BEHA-AMPROBE ALC-110-EUR leakage current clamp - 4930890

Product description:

• Designed in accordance with IEC/EN61557-13, VDE 0413-13
• The ALC-110-EUR True RMS leakage current clamp helps users measure, document and compare leakage current values over time.
• This is to prevent unplanned downtime and identify intermittent tripping by RCDs.
• Without the need to switch off equipment.
• The ALC-110-EUR is designed for industrial applications, such as leakage current testing in installations and for device testing.

Features:

• True RMS measurements for accuracy when measuring complex, non-sinusoidal waveforms
• Max readings and Hold function
• Measurement of earth fault currents
• Measurement of differential leakage currents
• Measuring leakage current through the earth (PE) conductor
• Tracing the source of earth leakage current
• Measurement of power consumption of devices in the maintenance or customer service sectors without circuit interruption

Additional info:

• Low influence of external low-frequency magnetic fields: At IN: 3,500 mA to 600,0 mA <= 30 A/m, operating class 2
• Mechanical jaw locking; jaw opening 30 mm (1.2 in)
• Highest resolution of 0.001 mA, measuring up to 60 A
• Selectable limit values: 0.25 mA, 0.5 mA, 3.5 mA, 10 mA, 12 mA
• Selectable filters:
• Function low-pass filter for measuring through equipment (according to IEC/EN 61557-16, modification A)
• 50/60 Hz filter
• No filter
• Main product features
• According to the standard for leakage current clamps IEC/EN 61557-13
• Selectable filter function eliminates unwanted noise
• Wide frequency range of 15 Hz to 1 kHz making this clamp ideal for a wide range of applications, including industrial and railway applications
• High safety specification: CAT III 600 V
• Automatic switch-off so batteries last longer
• Backlit display; automatic backlight and automatic display shutdown for longer battery life
