SKF SYWK 50 LTHR ball bearing unit 50 mm

Show more features

Shaft diameter

50 mm

Bore type

Cylindrical

Material (bearing housing)

Composite

Material (bearing)

Stainless steel

Material, bearing

Stainless steel

Sealing, bearing

Seal and flinger on both sides

Sealing type

Contact, multiple

Centre distance between bolt holes

159 mm

Centre height (pillow block)

57.2 mm

Lubricant

Grease

Number of bolt holes for fasteners

2

Basic static load rating

23.2 kN

Material, housing

Composite for the SKF Food Line

Bearing width, total

51.6 mm

Retaining feature, inner ring

Set screws

Rubber seating ring

Without

Note

Limiting speed with shaft tolerance h6

Grease fitting

Without

Sealing, unit

Optional end cover

Limiting speed

2,200 r/min

Fastening bolt hole type

Plain

Relubrication hole

Without

Housing overall width

60 mm

Basic dynamic load rating

29.6 kN

Coating

Without

Housing type

Pillow block
