4151-20 OHNE FEST Torque spanner TORCOFIX FS 14x18 40-200 Nm
Features
Controlled tightening of screws in the range of 5 - 200 N-m without scale,Permanently set, audibly and perceptibly deactivated and robust torque spanner with rectangular take-up for industry and crafts,Design: classified according to DIN EN ISO 6789:2003 type II class A, with a factory certificate
Accuracy +/- 3 % of the set scale value
The guideline of the standard (+/- 4 %) is exceeded,for controlled clockwise and anticlockwise tightening,robust,lacquered steel-tube construction with zinc-plated rectangular shank (9x12 mm,resp.
14x18 mm),release system provides a tactile and audible release signal,factory setting: 17.5 mm (9x12 mm) resp.
25 mm (14x18 mm),Operation only with insert tools of uniform pitch size - otherwise value shifts may occur.,depending on tool use, both forward (e.g.
Socket spanner) or laterally (e.g.
Interchangeable ratchet and socket spanner).,Depending on tool usage, either forward (e.g.
Socket spanner) or sideways (e.g.
If a fixed factory setting is required, please state the N-m value when ordering (price on request).
